Graph comparing the performance of a standard 3 brush generator with a fully regulated 2 brush generator.


Note that b         Note that both battery voltage and current output continue to rise when the 3 brush charging rate is set at approximately 8 amps, resulting in overcharging of the battery.                                                         The fully regulated 2 brush generator continuously varies current output in an effort to maintain but not exceed the desired battery voltage.
